Epoxy Standoff Insulators
Our Standard MV epoxy Standoff Insulators designed for voltages ranging from 2400 to 38kV, are essential components in electrical systems. These electrical standoff insulators are engineered to separate conductors, such as quarter-inch thick copper or aluminum bus bars, from the surfaces or components they are attached to.
Standard MV Epoxy Insulators (2400 to 38kV)
| Voltage (kV) | Part Number | Insert Pattern | Creep (mm) |
|---|---|---|---|
| 2.4 | N-002-0082-ASB-201 | X | 82 |
| 2.4 | N-002-0082-ASR-301 | X | 82 |
| 5 | N-005-0115-BSG-105 | A20-1 | 115 |
| 8 | N-008-0162-BSG-105 | A20-2 | 162 |
| 15 | N-015-0230-BSG-105 | A20-3 | 230 |
| 15 | N-020-0311-BSG-225 | A20-3 | 311 |
| 15 | N-015-0240-BBB-101 | Single | 240 |
| 25 | N-020-0311-BSG-105 | A20-4 | 311 |
| 25 | N-020-0311-BSG-225 | A20-4 | 311 |
| 25 | N-025-0348-BAG-105 | A20-5 | 348 |
| 25 | N-020-0295-BSG-105 | A30-4 | 295 |
| 35 | N-035-0485-BSG-105 | A20-6 | 485 |
| 38 | N-035-0555-BBB-1C3 | 3/1 Insert | 555 |
Commonly utilized in electrical switchgear, switchboards, control panels, and power distribution systems within substations, these insulators play a critical role in maintaining system integrity. Their high electrical resistance prevents unintended current flow between conductors and surrounding objects, minimizing the risk of damage and energy loss.
By ensuring there is no direct physical contact between electrical components, our epoxy insulators effectively reduce the likelihood of short circuits. This not only enhances the safety of the electrical system but also ensures optimal performance and reliability.
Our insulators are manufactured to meet the highest industry standards, offering durability and long service life even in the most demanding environments. They are resistant to environmental factors such as moisture, heat, and chemicals, ensuring consistent performance over time. Available in a variety of specifications to meet diverse application needs, many of our insulators are in stock and ready for prompt shipment. This allows for quick and efficient deployment in your electrical infrastructure projects, reducing downtime and keeping your operations running smoothly.
Our commitment to quality and customer satisfaction means that you can trust our MV Epoxy Insulators to deliver superior performance and reliability. Whether you are upgrading existing systems or installing new equipment, our insulators provide the dependable solution you need. Explore our extensive range today and find the perfect fit for your specific requirements.
